# Creating a Section

## Let's get slicey slicey!

The sectioning tools in Twinview facilitate the creation of cut sections in the 3D model, enhancing the ease of interaction with the model. Two primary types of section functionality are available: Section Planes and Section Boxes.

Section planes and boxes can be preserved by saving views in the 'View Tab' of the information palette. This feature is valuable for storing sections for future use or swiftly accessing specific views, such as 3D floor views.

![](https://4192331197-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2F0qVsdWLKUzgOfm7dGAeX%2Fuploads%2FbkeXsYZrUt2Dgr74sA7U%2FScreen%20Recording%202023-06-22%20at%2012.57.02.gif?alt=media&token=77eb9ebe-ff91-4431-bb75-ce3636d34fe2)

### Section Planes

<https://content.twinview.com/knowledge-base/user-interface-and-navigation/creating-a-section#section-planes>

Section planes can be accessed through the Section tool button in the bottom View Toolbar. This tool enables the cutting of a single section along a designated plane. Once activated, the section can be easily adjusted and manipulated using the on-screen transform tools.

![The Twinview Section Plane Tool](https://tawk.link/6139b70425797d7a89fe0906/kb/attachments/i8sbv3BtJe.png)

### Section Box

<https://content.twinview.com/knowledge-base/user-interface-and-navigation/creating-a-section#section-box>

The section box can be accessed by clicking the Section tool button in the bottom toolbar. It provides a 6-sided cropping box that allows you to section your model effectively.

By default, the cropping box encompasses the entire model. Nevertheless, each section face can be individually adjusted by clicking on the face of the section box and utilising the yellow arrow transform tool to push or pull as desired.

![The Twinview Section box tool](https://tawk.link/6139b70425797d7a89fe0906/kb/attachments/Ds0A2ZXbfl.png)

### Video of the Sectioning Tools in Twinview

<https://content.twinview.com/knowledge-base/user-interface-and-navigation/creating-a-section#video-of-the-sectioning-tools-in-twinview>

A short video walkthrough showing the sectioning tools in Twinview

<iframe width="750" height="422" src="https://www.youtube.com/embed/3EN41JMeNmk" title="Sectioning tools in Twinview" frameborder="0" allow="accelerometer; autoplay; clipboard-write; encrypted-media; gyroscope; picture-in-picture; web-share" allowfullscreen style="position: absolute; top: 0px; left: 0px; width: 100%; height: 100%; border: none;"></iframe>
